Build Your Starlink Mini Mount.
One mount. Configured to match your vehicle, your rack, and your power setup.
The SVNTY OFFROAD Starlink Mini Mount is an Australian-made mounting system built to keep your Starlink Mini secure, protected, and ready to go - wherever you're taking it. Every mount includes a full Anti-Shock EVA Foam Cradle that isolates the dish from vibration and impact, so it's not just sitting on bare metal soaking up every corrugation, pothole and gravel track underneath it.
Use the options below to configure exactly the setup you need - colour, power, and mounting hardware in one place, without piecing it together from separate listings.
Every Mount includes:
- SVNTY OFFROAD Starlink Mini Mount
- White Protective Cover
- Anti-Shock EVA Foam Cradle
1. Choose Your Mount Colour
Black or White powder coat.
2. Choose Your Power Setup
- Standard - Just the mount, no integrated power connector. Ideal if you're wiring your own setup or don't need one built in.
- Anderson Plug with 25cm Cable - Adds a clean, accessible Anderson connection to the standard mount for a tidy power setup.
- Anderson Plug with Step-Up Booster - Our complete power solution. Integrated Anderson connection plus a 12V → 30V IP68 step-up voltage booster with 25cm Anderson-to-Starlink DC cable, so you can run straight off a suitable 12V vehicle system.
- Deutsch Plug with Step-Up Booster - Same 12V → 30V IP68 step-up booster and cable, in a compact Deutsch-connected setup for a neat, secure install.
3. Choose Your Fastener Bolt Kit
- M8 Channel Nut - Thick
- M8 Channel Nut - Thin
- M8 Nyloc Nut
- M8 Square Nut
- No Bolt Kit
Each kit includes four M8 bolts, washers and nuts. Not sure which one suits your rack? Check our fitment guide, or select No Bolt Kit if you've already got suitable M8 hardware on hand.
Need A Different Mounting Setup?
Not bolting to a roof rack? Our Magnetic Feet turn the mount into a strong, fully removable setup for suitable steel roofs, canopies, tool boxes and other steel surfaces - no drilling required.
Running an ARB Base Rack? A dedicated bridging bracket setup is available to mount securely across the ARB Base Rack structure. Choose the M8 Nyloc Nuts kit when configuring your Starlink Mini Mount.
Need an extra lid? Your mount comes with a white cover as standard. Additional protective covers are also sold separately in Black, White and Clear - handy for replacing a worn cover or changing up the look of your setup.
Built For Wherever Work And Life Take You
Designed and made in Queensland, Australia, the SVNTY OFFROAD Starlink Mini Mount was engineered to survive corrugations, endless kms of dirt road and constant vibration - the kind of punishment that ends a touring trip early if your gear can't take it. But "built tough enough for the outback" turns out to be useful for a lot more than the outback.
It's just as at home on a tradie's ute doing the school-run-to-job-site shuffle every day, on a remote worker's vehicle holding a signal on a mine site or in the middle of a paddock, on a farm ute or piece of ag equipment covered in dust for ten hours straight, on a government or council fleet vehicle that needs gear that won't need replacing every six months, on a caravan or camper trailer that only sees corrugations twice a year, or simply on a daily driver in the suburbs where reliable internet just needs to show up and work. Wherever it ends up, the same Anti-Shock EVA Foam Cradle is doing the same job: keeping the dish isolated from vibration and protected from direct contact with the metal mount, day in, day out.
Choose your colour. Choose your power setup. Choose your hardware.
One Starlink Mini Mount. Built your way, for wherever "your way" happens to be.
Starlink Mini dish not included.
Reliable 12V Power For Starlink Mini
The SVNTY OFFROAD Starlink Mini Mount Booster includes a high-efficiency DC-DC converter that safely steps your vehicle’s 12V supply up to the optimal 30V to power the Starlink Mini.
This allows Starlink Mini to run directly from:
- Vehicle accessory circuits
- Auxiliary battery systems
- Portable battery banks
- Off-grid touring setups
Designed for reliability in harsh Australian touring conditions, the converter is sealed, efficient, and protected against voltage spikes and overheating.
Model No. DCDC12S30
- Input Voltage 12V DC
- Output Voltage 30V DC
- Output Current 3.5A
- Efficiency 94%
FEATURES
- Non-isolated between input and output
- Internal capacitor: NCC & NICHICON
- 100% full load burn-in test
- Over-voltage, overload, over-temperature protection
- Waterproof rating IP68
- 12 months warranty
WORKING SCHEMATIC
Battery Bank/Other → DC-DC Converter → Load
SPECIFICATIONS
Input
- Rated Voltage 12V
- Voltage Range 9-28V
- Efficiency 94%
- Positive cable (red) 50A Anderson total length 80mm
- Negative cable (black) 50A Anderson total length 80mm
Output
- Voltage 30V
- Maximum rated current 3.5A
- Maximum rated power 105W
- Voltage regulation +/- 1%
- Load regulation +/- 2%
- Ripple and noise <150 mV (full load)
- Output cable 260mm
Function
- Waterproof IP68
- Over temperature protection YES
- Over voltage protection YES
Mechanical
- Weight 150g
- Size 65x62x22mm
Why A DC-DC Converter Is Required
Starlink Mini requires 30V DC input, while most vehicle electrical systems supply 12V.
The included converter safely boosts voltage while maintaining stable output, protecting the Starlink Mini from:
- voltage drop
- unstable vehicle electrical systems
- overload conditions
Starlink Mini Power Consumption And 12V Battery Setup
How Much Power Does Starlink Mini Use?
Starlink Mini typically draws 20–60 watts during normal operation, depending on network activity and signal strength.
During initial startup or heavy data usage, power consumption can briefly increase.
| Mode | Typical Power Draw |
|---|---|
| Idle / Low Activity | 20–30W |
| Normal Operation | 30–45W |
| Heavy Data Use | Up To 60W |
Because Starlink Mini requires 30V DC input, most 12V vehicle systems cannot power it directly.
The SVNTY OFFROAD Starlink Mini Mount Booster includes a high-efficiency 12V to 30V DC-DC converter that allows the unit to run safely from:
- 12V vehicle batteries
- auxiliary battery systems
- portable power stations
- off-grid touring setups
This eliminates the need for a 240V inverter, improving efficiency and reducing unnecessary battery drain.
Why Use A DC-DC Converter Instead Of An Inverter?
Running Starlink Mini through a 240V inverter wastes power because electricity must be converted twice.
12V → 240V → 30V
The SVNTY OFFROAD power booster uses a direct 12V → 30V conversion, which is significantly more efficient.
Benefits include:
- longer battery runtime
- less heat generation
- reduced load on your electrical system
- simpler installation
Engineered For Reliable Power And Built For Real Off-Road Touring, The SVNTY OFFROAD Starlink Mini Booster Keeps You Connected Wherever The Track Leads.
